Introduction
Minimalist Design:3U standard modular, fast installation;
Easy maintenance and expansion.
Ultra-Long life:Ultra-long cycle cell, design life of 15 years,
The system can reach 6000 cycles
Intelligent Management:The system adopts a three-level architecture. Automatically identify the number and address of modules, configure LCD.
High Security:Sunrf's self-produced 100Ah
LFP Prismatic Cell, which is highly safe and reliable.
Flexible Configuration：Multi-module series, to meet the voltage platform,capacity level and power requirements
Easy maintenance and expansion.
Ultra-Long life:Ultra-long cycle cell, design life of 15 years,
The system can reach 6000 cycles
Intelligent Management:The system adopts a three-level architecture. Automatically identify the number and address of modules, configure LCD.
High Security:Sunrf's self-produced 100Ah
LFP Prismatic Cell, which is highly safe and reliable.
Flexible Configuration：Multi-module series, to meet the voltage platform,capacity level and power requirements
Parameter
| Model | SUN-SDC10-Box5 | SUN-SDC10-Box10 | SUN-SDC10-Box15 | SUN-SDC10-Box20 |
| Battery Module | Box5*N | |||
| Cell Type | 100Ah LFP Prismatic Cell | |||
| Number of Modules | 1 | 2 | 3 | 4 |
| System Nominal Energyt | 5.12kWh | 10.24kWh | 15.36kWh | 20.48kWh |
| Available System Nominal Energy | 4.86kWh | 9.72kWh | 14.6kWh | 19.45kWh |
| Nominal Voltage | 51.2V | |||
| Operating Voltage Range | 45.0-56.4V | |||
| Max.Output Power | 4.1kW | 5.12kW | 7.68kW | 10.24kW |
| Peak Output Power | 5.4kW,10S | 10.0kW,10S | 15.0kW,10S | 15.0kW,10S |
| Max.Charging Current | 50A | 100A | 150A | 150A |
| Max. Discharge Current | 100A | 150A | 190A | 230A |
| General | ||||
| Dimensions [W*H*D] | 443*135*440mm | 484*330*440mm | 484*495*440mm | 484*660*440mm |
| Weight | 40kg | 85kg | 127.5kg | 170kg |
| Communication | CAN/RS485 Rack/Wall Mounted |
|||
| Installation | Rack/Wall Mounted | |||
| Enclosure Rating | IP20 | |||
| 25C Cycle Life | ≥6000Cycles @80%DOD&70%EOL | |||
| Operating Temperature | Charge:-5~45℃; Discharge: -20~50℃; Recommended: 15~35℃ 5%~95%[Non-Condensing] Natural Cooling |
|||
| Operating Humidity | 5%~95%[Non-Condensing] | |||
| Cooling Mode | Natural Cooling | |||
| Operating Altitude | ≤4000m | |||
| Matching Inverter | Deye,Growatt,Goodwe,Victron,Sofar,SMA ,SRNE,LUX,Solis, TBB,Soruide,Megarevo,Sungrow,Afore,Sacolar,SMK solar,Voltronic |
|||
